In this project, we designed and prototyped a 3-axis milling machine to manufacture PCBs. The machine body could be made from either iron or aluminum. We used stepper motors for the linear motion of axes and an induction motor as the spindle. For more information, please send a message via the contact form. https://youtu.be/5vF3jCRMwAM
In this project, we developed an application for the design and analysis of a double rotor axial flux motor. The analytic design is done by Excel. You can see a short review of the project in the video below!
In this project, a single-phase induction motor for a high-speed fan application was investigated. Download Report File
In this project a 3HP, 3000RPM permanent magnet assisted synchronous reluctance motor was designed for pumping application. A software tool developed for analytic & FEA design of motor using EMDLAB package. The below figure shows the sketch of the motor: The below figure shows the software: Design Steps: Analytic design using object oriented programming in MATLAB Calculation…
In this project a 30kW, 20kRPM surface permanent magnet synchronous motor was designed for CNC application. The below figure shows stator limination.
