Course Title:

Magnetic Equivalent Circuit (MEC) Analysis of Induction Motors by ANSYS Simplorer

Course Contents:

  • 12 live Skype meetings, every meeting between 1.5~2hr
  • Discussion on analytic design of the motor in Excel
  • Generation of the MEC model of induction motor in ANSYS Simplorer
  • Derivation of static and dynamic characteristics of the motor using MEC method
  • Comparison of the derived results with the MEC method with the counterpart finite element results
